Debug and Visualize

Retriever debugging should start before a robot backend is involved. Use one source graph and move through four views: render the graph, step it locally, visualize events, then record and replay the same run.

Fast Path

Run these in order when a graph feels wrong:

pixi run docs-tutorial-perception-html
pixi run demo-stepper
pixi run demo-webcam-detection-mock
pixi run demo-webcam-record
pixi run demo-webcam-replay-rrd

Stage	Question it answers	Artifact to inspect
Render	Did I wire the graph I intended?	artifacts/tutorial_perception.html
Step	Does Flow logic work in ordinary Python?	stdout step trace
Mock perception	Does perception work without camera or GUI risk?	stdout detection events
Record	Can I preserve the run as evidence?	logs/perception.rrd, logs/perception.mcap
Replay	Can I debug the same events again?	replay stdout and recorded events

The Debug Loop

1. Inspect structureRender the graph before changing runtime code. Ports, clocks, sync policies, and feedback edges should be visible.

2. Prove local logicUse the stepper path to set breakpoints in Flow.step(...) without backend scheduling noise.

3. Remove hardware riskUse mock perception before live camera or Rerun. The output should be deterministic.

4. Save evidenceRecord once, replay many times, then share the exact artifact instead of a timing-sensitive anecdote.

1. Render The Graph First

pixi run docs-tutorial-perception-html

Typical output:

[Success] Visualization saved to: artifacts/tutorial_perception.html
Open this file in your browser to view the interactive graph.

Open the generated HTML and check these before debugging backend behavior:

• Flow nodes: is every module present?
• Ports: do input and output names match what the code expects?
• Clocks: which Flow wakes itself, and which Flow wakes on upstream events?
• Sync policies: how is upstream history sampled before step(...) runs?
• Feedback edges: where can closed-loop state re-enter the graph?

If this graph is wrong, fix wiring first. Do not start by debugging multiprocessing, Rerun, or camera setup.

Live graph

The perception pipeline, rendered by the runtime

The same interactive HTML pipe.visualize() writes — pan, zoom, and inspect nodes, ports, clocks, and sync policies inline.

Open full graph

2. Step Locally

pixi run demo-stepper

Typical output:

=== step 0 ===
[Sink] got value=2

=== step 1 ===
[Sink] got value=4

Use local stepping when you want to set breakpoints inside Flow.step(...), inspect local state, or reduce a backend issue to a small deterministic case. The mental model is ordinary Python:

pipe.validate()

for _ in range(10):
    result = pipe.step(dt=0.1)
    print(result.executed)

pipe.close_stepper()

For perception-specific stepping without camera permissions or GUI windows:

pixi run demo-perception-stepper

Set a breakpoint in Flow.step() (VS Code)

This is the payoff of stepping: pipe.step() runs the whole graph in your own Python process, so a normal debugger stops inside your Flow with full locals. No backend process to attach to, no remote debugger.

1. Put a breakpoint in the Flow you want to inspect:

   class ColorDetector(Flow[CameraOut, Detections]):
       def step(self, input: CameraOut) -> Detections:
           hsv = to_hsv(input.image)        # ← breakpoint here
           hits = self.match(hsv)
           return Detections(objects=hits)

2. Run the stepper script under the debugger — VS Code Run and Debug (F5) on the file that calls pipe.step(), or attach to pixi run demo-stepper.

3. Execution stops on that line. In the Variables pane you can read input._signals (which ports fired), self state carried between steps, and every intermediate — then step through match() line by line.

Because the stepper is single-process and synchronous, pipe.step(dt=0.1) advances one tick and returns; the debugger treats your Flow like any other function. Get the logic right here first — then run it on multiprocessing or dora, where each Flow is a separate process and breakpoints are far harder.

3. Visualize Perception Safely

Start with mock frames and stdout. This is the reliable path for laptops, CI, remote machines, and AI-agent verification.

pixi run demo-webcam-detection-mock

Typical output includes:

Building perception pipeline:
  Camera @ Rate(20Hz) -> ColorDetector @ Trigger -> Display @ Rate

Graph created: 3 nodes, 5 edges
Frame 1: 2 objects - [('red_object', '0.95'), ('blue_object', '0.95')]

Then switch to a live webcam path:

pixi run demo-webcam-detection

That command uses real camera input with --visualize auto: Rerun when a viewer is available, stdout otherwise. Use Rerun when you need to inspect image frames, detections, and timing visually. Use stdout when the question is simply whether the graph runs and emits events.

Useful variants:

pixi run demo-webcam-detection-mp-rerun
pixi run python -m examples.tutorial.b_ir_and_execution.06_dora_perception \
  --backend in-process \
  --camera-mode mock \
  --visualize stdout \
  --duration 10

4. Record And Replay

pixi run demo-webcam-record
pixi run demo-webcam-replay-rrd

The record command writes replayable artifacts:

logs/perception.rrd
logs/perception.mcap

Replay consumes recorded events instead of relying on live camera timing. Use this when behavior changes between runs, when you need to share evidence, or when downstream logic should be debugged without a sensor attached.

Practical Triage

Symptom	First action	Why
Graph shape is surprising	Render artifacts/tutorial_perception.html	Wiring, clocks, ports, and sync policies are visible there.
Flow output is wrong	Run demo-stepper or demo-perception-stepper	Keeps debugging in ordinary Python before backend scheduling enters.
Rerun does not open	Force stdout visualization with the command below	Separates runtime correctness from viewer setup.
Webcam is unreliable	Use pixi run demo-webcam-detection-mock	Proves the graph without hardware or permissions.
Run is hard to reproduce	Run pixi run demo-webcam-record, then pixi run demo-webcam-replay-rrd	Turns timing-sensitive input into a stable artifact.
Backend differs from local stepping	Compare stepper output, rendered graph, and backend output	Clock/sync choices are often the real difference.

Exact stdout fallback when viewer setup is the suspected issue:

pixi run python -m examples.tutorial.b_ir_and_execution.06_dora_perception \
  --backend in-process \
  --camera-mode mock \
  --visualize stdout \
  --duration 10

What To Save When Asking For Help

If you need another person or an AI agent to debug the run, include these instead of a screenshot alone:

• the command you ran, including --backend, --camera-mode, and --visualize;
• artifacts/tutorial_perception.html when graph shape is relevant;
• the first 20-40 lines of stdout around the failure;
• logs/perception.rrd or logs/perception.mcap when the issue depends on live sensor timing;
• whether the failing path used mock frames, live webcam, Rerun, multiprocessing, or Dora.

That bundle lets the next reader distinguish graph wiring, Flow logic, viewer setup, sensor timing, and backend scheduling.

Continue

• Use Examples and Results for notebook-style expected outputs.
• Use Time and Sync if the issue is event timing or edge sampling.
• Use the first GoldenRetriever proof after the core visual debugging path works.
